Overall Operating Weight

8200KG

Final Reducer

Single Stage Final Reducer

Transport Dimension

Rated Loader of Axle

8/18.5t

mm L*W*H

592022503770

Transmission System

 Wheel base

2200mm

Torque Converter

 Min. Ground Clearance

300mm

Model

YJ280

 Bucket Capacity

1.0m³

Type

Single-stage Three Elements

Breakout Force

38KN

Max. Efficiency

84.4%

Loading Lifting Capacity

2500KG

Inlet Pressure

05Mpa

Bucket Dumping Height

2742mm

Outlet Pressure

1.1Mpa1.3 Mpa

Bucket Dumping Distance

925mm

Cooling Method

Oil-cooling Pressure Circulation

 Digging Depth

52mm

Gearbox

Backhoe Capacity

0.3 m³

Type

Fixed Shaft Power Transmission

Max. Digging Depth

4082/4500mm

Oil Pressure of Clutch

1373Kpa1569 Kpa

Swing Angle of Excavator Grab

190^o

Gears

22Two Gears Ahead, Two Gears Astern

Max. Pulling Force

39KN

Max.Speed

28Km/h

Engine

Tyre

Model

YC4A105Z-T20

Model

14-17.5/19.5L-24

Type

In Line Direct injection Four-Stroke and Injection Combustion Chamber

Pressure of Front wheel

0.55Mpa

-*Cylinder-Inside Diameter*Stroke

4-102120

Pressure of Back Wheel

0.223Mpa

Rated Power

75KW

Brake System

Rated Speed

2200r/min

Service Brake

Air Over Oil Caliper Brake

Min. Fuel Consumption

242g/km.h

External Type

Max.Torque

410N.M

Self-regulation

Displacement

4.4L

Self-balance

Steering System

/Emergency Brake

Operation Power Implementing brake

Model of Steering Device

BZZ5-250

Manual Operation Power Terminating Brake

Steering Angle

36 ^o

Hydraulic System

Min. turning radius

6581mm

Digging Power of Excavator Grab

46.5KN

Pressure of the system

12Mpa

Digging Power of Dipper

31KN

Axle

Bucket Lifting Time

68S

Manufacturer

Feicheng Axle Factory

Bucket Lowering Time

3.1S

Main Transmission Type

Double Reduction

Bucket Discharge Time

2.0S

The parameters are subject to change without notice
